10 Foot Wide Aluminum Sliding 2-Panel Panoramic Patio Door Thermal (Multiple Heights)

Heavy-Duty Exterior Sliding Door

2-Track, 2-Panel System 10' Wide

Upgrade your space with our high-performance Thermal Break Aluminum Sliding Glass Door, a top-tier choice for modern home and commercial applications. Engineered for maximum durability, thermal efficiency, and superior wind resistance, this heavy-duty exterior sliding door combines sleek aesthetics with cutting-edge functionality.

Product Overview

• Profile Material: 6063-T5 Aluminum Alloy (2.2mm thick for unmatched strength)
• Frame Depth: 217mm | 2 Tracks, 2 Panels
• Frame Finish: Black Powder-Coated for a sleek, corrosion-resistant look
• Glass Type: 5+27A+5mm Double Tempered Glazing with Argon Gas Fill
• Tracks: SUS304 Stainless Steel for long-lasting smooth operation
• Package: Includes fully enclosed wooden crate for maximum protection

Key Features & Benefits

Unmatched Strength & Durability

• 2.2mm thick aluminum frame—far superior to standard market options.
• SUS304 Stainless Steel tracks ensure smooth, rust-resistant sliding for years.
• Heavy-duty locking core with key double door system for enhanced security.

Superior Thermal Efficiency

• Thermal Break Technology prevents heat transfer, keeping indoor temperatures stable.
• 5+27A+5mm Double Tempered Glass with Argon Gas Fill—argon is 6 times denser than air, enhancing insulation.
• Hidden drainage system and three-seal design provide maximum waterproofing.

Extreme Weather & Wind Resistance

• Certified for high wind loads up to 4500 Pa (4.5 kPa)—5x stronger than most doors rated at only 800 Pa.
• Waterproof & airtight sealing—designed for all climates, from coastal storms to extreme cold.
• Hurricane-rated for safety and protection against extreme weather conditions (not Miami-Dade rated).

Noise Reduction & Security

• 30 dB Sound Insulation—ensuring peace and quiet inside your home.
• Six-point locking system with anti-theft flyscreen for added security.
• Impact-resistant double-tempered glass—built to last and resist damage.

Performance Ratings

• Air Permeability: 4.5 m³/m·h
• Water Tightness: TS EN 12208, 300 Pa
• Wind Load Resistance: TS EN 12210, 4500 Pa
• Thermal Insulation: Uw: 2.3 W/m².K
• U-Factor: 0.29 & SHGC: 0.23

Customization Options

We offer fully custom-sized doors to fit your exact needs. Whether you need a specific width, height, or frame color, our doors can be tailored to your residential, commercial, or luxury project.

• Choose from multiple frame colors
• Custom glass options available
• Global shipping available

Order Process & Lead Time

• Custom Manufacturing – All doors are made-to-order for 2025 production.
• Lead Time: 10-12 weeks (may vary based on location and custom options).
• Confirmation Process: A team member will contact you to confirm dimensions, color, and glass options.
• Final Invoice: You will receive a detailed order confirmation document to approve before production begins.

Shipping & Delivery

• FREE Nationwide Shipping via freight or private carrier.
• Each order is professionally crated ($1,000 value) to prevent damage during transit.
• Tracking and updates provided throughout the process.
• Important: Inform your contractor in advance about the arrival date to plan for unloading and installation.
